Case Studies

Our products have been adopted by various companies and institutions throughout the world and our
history since 1959. Here we would like to present a few of our accomplishments over the years.

  • The world ‘s first 3D printing technology for drinkable liquids

    Miniature Peristaltic Pumps

    The world ‘s first 3D printing technology for drinkable liquids

    The world ‘s first 3D printing technology for drinkable liquids

    PRINT A DRINK Technology Enables Unique Service   PRINT A DRINK in Austria is the world ‘s first 3D printing technology for drinkable liquids. With their high-end industrial robot, they can inject microliter-drops of edible liquid into a cocktail. Within a minute, PRINT A DRINK can build up complex 3D structures in a wide range of drinks. Our ultra-small solenoid diaphragm valves, the NV series, are used in their prototype of the 3D printing machines! Challenges and Solutions Takasago was given a challenge to meet the following valve requirements. 1. Small size is required to design the device to be...

  • Takasago’s Products used in Micro Gas Chromatography Instruments

    Miniature Peristaltic Pumps

    Takasago’s Products used in Micro Gas Chromatography Instruments

    Takasago’s Products used in Micro Gas Chromatography Instruments

    Ball Wave is a startup company from Tohoku University that does R&D on sensors, as well as manufacture and sell devices that use these sensors. The concept of, ‘A wave which propagates on the surface of a sphere over a long distance maintains the same width’ was key to the development of the Ball SAW (Surface Acoustic Wave) sensor. These sensors are compact, have high sensitivity and rapid response. Products that use Ball SAW sensors are ultratrace moisture analyzers and micro gas chromatography instruments. Challenges and Solutions The Ball Wave micro gas chromatography instrument was developed in collaboration with JAXA...

  • Adoption of "SBP Series Syringe Pump" at Tokyo Jikei University School of Medicine

    Miniature Peristaltic Pumps

    Adoption of

    Adoption of "SBP Series Syringe Pump" at Tokyo Jikei University School of Medicine

    Research on "Regenerated Kidneys produced in Animal Embryos"   Cell transplantation into Mouse Embryos using a SBP series Pen-Type Syringe Pump. Dr. Shuichiro Yamanaka from the Department of Nephrology and Hypertension, Tokyo Jikei Medical University (Japan), is researching kidney regeneration as a new treatment for renal failure. In order to regenerate a functional kidney, a kidney bud, also called a "Kidney Seed," is made. Previous studies have shown successful transplantation of "Kidney Seed" into rats with renal failure to produce urine (Yokote S, PANS, 2015, Fujimoto T, Cell Reports, 2020). Challenges and Solutions To make a "Kidney Seed," stem cells...

  • Diram s.r.o.

    Miniature Peristaltic Pumps

    Diram s.r.o.

    Diram s.r.o.

    The Diram s.r.o. in Czech Republic Chez has been developing and manufacturing equipment for devices used in the electrochemical analysis, measuring radiation, microscopical image analysis, and analyzing waste. Our high-pressure 3-way valves are used in Diper 4K/50, which elutes heavy metal included in landfill wastes. Challenges and Solutions Takasago was given the challenge to meet the following valve requirements: - Chemically harsh liquid, which decays metal, is used in the device, and all wetted materials should be non-metal. - High pressure is required to conduct elution into the sample in the cylinder. Takasago’s MTV series met all the requirements above,...

  • the University of Tokyo

    Miniature Peristaltic Pumps

    the University of Tokyo

    the University of Tokyo

    Contribution to new drug development by mimicking an in vivo environment “Project T” introduces the people who are working in association with Takasago Fluidic Systems and the unique projects, daily efforts, results, and difficulties they came across. In 2018, the Sakai/Nishikawa Laboratory in the University of Tokyo Department of Chemical Engineering Systems faced an issue while developing the Intestinal Micro physiological System (MPS) Device. The purpose of this device was to reproduce the human intestinal environment as a part of a project to imitate the human body promoted by the Japan Agency of Medical Research and Development (AMED). The project...

  • Techshot, Inc.

    Miniature Peristaltic Pumps

    Techshot, Inc.

    Techshot, Inc.

    Contributing to regenerative medicine experiments in microgravity. Techshot research equipment sent to the International Space Station (ISS) for the MVP Cell-03 experiment and our small peristaltic pump used in the equipment. Astronaut Serena Auñón-Chancellor loading experiment modules into a Techshot MVP Techshot Inc., is a company that designs, develops and commercially operates its own research and manufacturing equipment in space. Its customers include NASA and several universities and commercial companies. The small peristaltic pumps, RP-Q Series sold by Takasago, have been adopted as one of the key components in experiment modules used inside the Techshot Multi-use Variable-gravity Platform (MVP) payload...

  • NASA Glenn Research Center

    Miniature Peristaltic Pumps

    NASA Glenn Research Center

    NASA Glenn Research Center

    Small pumps used for single layer liquid crystal formation and defect generation mechanism analyzer in zero gravity As part of the "OASIS" (Observation and Analysis of Smectic Islands in Space) project that was tested inside the International Space Station (ISS) in 2015, the formation of single-layer liquid crystals and the analysis of defect generation mechanisms in zero-gravity were performed, which is difficult to reproduce on Earth. The aim is to design liquid crystal display (LCD) that can better perform in outer space. The experimental analyzer was equipped with Takasago ultra-compact pumps (syringe type and tubing type). Challenges and Solutions To...

  • Blossom Coffee, Inc.

    Miniature Peristaltic Pumps

    Blossom Coffee, Inc.

    Blossom Coffee, Inc.

    Professional coffee brewer incorporated custom pinch valves with excellent heat resistance Blossom Coffee, Inc. is a design and development company in San Francisco, USA specializing in coffee equipment. The newly developed coffee brewer is a professional grade product that can control the supply temperature of beans and hot water that affects the taste and aroma of coffee in the range of 50 to 95 ° C in 0.5 ° C increments. This special brewer has been introduced in global media, such as ABC and BBC networks, and are also sold worldwide including Japan. Challenges and Solutions During early stages of...

  • Valley Christian School

    Miniature Peristaltic Pumps

    Valley Christian School

    Valley Christian School

    Valley Christian School in U.S.A. –Adoption Example RP-Q1 overcomes a limited space and power consumption and was launched to the International Space Station (ISS) in 2014’s summer Valley Christian School is a private, K-12 Christian School located in the heart of Silicon Valley, San Jose, California. This school develops and manages the ISS (International Space Station) project and provides modules, software and knowledge to participating schools who want to run their own experiments on the ISS. Valley Christian School was developing two ISS project experiments which used the RP-Q1. The first was run by the junior high school to examine...

  • JAMSTEC Adoption example

    Miniature Peristaltic Pumps

    JAMSTEC Adoption example

    JAMSTEC Adoption example

    Challenge of miniaturization and power saving. Automatic measurement of CO2 concentration on ocean surface. Measurement of CO2 on ocean surface*Images courtesy of JAMSTEC Inside the CO2 measurement buoy Japan Agency for Marine-Earth Science and Technology (JAMSTEC) used a ship to monitor the concentration of CO2 on the sea in order to more accurately grasp the distribution of the absorption / release of CO2, one of the greenhouse gases, on a global scale. But they felt the limitations of the conventional method, and developed the "CO2 measurement buoy" to measure while drifting on the ocean surface. Our products are used as...

  • Kumamoto University in Japan

    Miniature Peristaltic Pumps

    Kumamoto University in Japan

    Kumamoto University in Japan

    Customer’s field and the device features A Portable μTAS (micro Total Analysis Systems), which is an analytical instrument that uses micro-channels to detect the concentration of the atmospheric pollutant gasses SO2 and H2S. Customer’s problems and our solutions The customer’s wished to downsize an application that pours 10~20μL/min of diluted sulphuric acid and fluorescein mercury acetate (FMA) into a micro-channel, such that it becomes portable. In response, we proposed a small, lightweight and highly inert shape memory alloy driven valve as a miniature pump and achieved the customer’s requirements. Result The customer succeeded in developing a small sized portable analyzer...
