Stepper Motor Type of RP-QⅡ/RP-QⅢ Series

$122.00 USD

Variation
Quantity

FEATURES / CHARACTERISTICS



Fingertop Size Peristaltic Pump

  1. Compact dimensions
  2. Discharge (flow) rate range of 3 ~ 1,100 μL/min or 0.06 ~ 60 μL/min by stepper motor
  3. Detachable / Replaceable Pump Head
  4. Pump head may be sterilized by autoclave or gamma ray
  5. Tubing options of Silicone or Pharmed®
  6. Suitable for analytical instruments, medical devices, fuel cells, drug delivery systems, regenerative medicine (cell culturing), etc.

Note: Details such as specifications, etc., may be changed without notice.


We also have a similar product to this pump, it's called:

  1. Peristaltic Tubing Pump - RP-Q series

MECHANISM OF THE RING PUMP

Mechanism of Ring PumpMechanism of Ring Pump

Mechanism of Ring Pump

Aquatech Co., Ltd. logo

For more information:

Mechanism of the Micro Peristaltic Pump

Note 1: Details such as specifications, etc., may be changed without notice.

Note 2: Visual diagram above is from Aquatech Co., Ltd.

VIDEOS OF THE RP-Q SERIES




Note: Details such as specifications, etc., may be changed without notice.

SPECIFICATIONS

Swipe left to see the remaining contents

Model Number RP-QⅡ / RP-QⅡ & QⅡX / RP-QⅢ
Motor 2-Phase Bipolar Type Stepper Motor
Pump Method Peristaltic Pump
Type Miniature Peristaltic Pump
Rated Voltage 3.6 ~ 3.3 VDC
Power Consumption 350 mW
Tube Material Silicone or PharMed®
Pumped Volume Adjustable Range 3 ~ 1,100 μL/min or 0.06 ~ 60 μL/min by stepper motor
Maximum Pumped Pressure ≧30kPa
Weight Approximately 11~13 g
Remarks Mounting Flange: None (Optionally Mounting Clip, for RP-QⅡ / RP-QⅡ & QⅡX) / Equipped (RP-QⅢ)
Pump Head Replacement Possible (*2)
Notes
Model Number Discharge Rate (μL/min)(*1) Tube Material
RP-QⅡC1.5S-1P1A-DC3VS 3 ~ 1,100 uL/min Silicone (I.D. 1.5 × O.D. 2.5 mm)
RP-QⅢC1.5S-1P1A-DC3VS
RP-QⅡBP5S-P06A-DC3VS 0.06 ~ 60 uL/min Silicone (I.D. 0.5 × O.D. 1.5 mm)
RP-QⅡBP5F-P06A-DC3VS PharMed® (I.D. 0.5 × O.D. 1.5 mm)
RP-QⅢBP5S-P06A-DC3VS Silicone (I.D. 0.5 × O.D. 1.5 mm)
RP-QⅢBP5F-P06A-DC3VS PharMed® (I.D. 0.5 × O.D. 1.5 mm)

Note *1: ±20%, Water at 25°C, Pulse Speed: 1 ~ 1000 pps.

Note *2: Autoclave (121°C 25 min) or Gamma Ray (25 kGy) only once.

Note: Details such as specifications, etc., may be changed without notice.


Motor Controller RE-C200/C201 at: 1 ~ 1000 PPS Drive

PC programmable Controller RE-C200: Master Controller Unit

Item Specifications
RE-C200
Input Voltage 5 VDC, 0.5 A (USB Supply)
Output Voltage 2.6 VDC
Motor Speed 1 ~ 2000 pps
Number of Pumps Connectable 1 piece
External Dimensions 100 x 100 x 35 mm
Weight Approximately 143 g

PC programmable Controller RE-C201: Slave Controller

Item Specifications
RE-C201
Input Voltage 5 VDC 3.0 A (100-240 VAC Adaptor Included)
Output Voltage 2.6 VDC
Motor Speed 1 ~ 2000 pps
Number of Pumps Connectable Up to 4 pieces (RE-C201) + 1 piece (RE-C200)*
External Dimensions 100 x 160 x 45 mm
Weight Approximately 227 g

Note *: Must be connected to Master controller RE-C200. RE-C200 may connect to 2 Slave controllers RE-C201.

Note: Details such as specifications, etc., may be changed without notice.
