Proportional Diaphragm Valve - NPV Series
Inquiry
searchsearchSearch by Specifications

Proportional Diaphragm Valve - NPV Series

Features

  • Has a very high chemical resistance due to all PTFE wetted parts.
  • Flow is controllable by changing the input voltage.
  • Has a comparatively large orifice diameter of 4 mm, which can cover a wide range of flows.

Specifications

Model Number NPV-4T1/8 (1/4)
Type N.C. (Normally Closed) Proportional Type
Orifice Diameter 4 mm
Port Connection Rc1/8, Rc1/4
Wetted Material PTFE (Valve Body, Diaphragm)
Operating Pressure Range 0 - 100 kPa
Flow Control Range 0 - 30 l/min (ΔP=10 kPa, Air)
0 － 4 l/min (ΔP=100 kPa, Water)
Power Consumption 7 W (at 24 V DC)

Note: Specifications etc. may be changed at any time without notice.


Flow Characteristics

Flow Characteristics


*Note (Left Graph): Volume flowing in 1 minute and measured by gravimetry.

*Note (Right Graph): Measured by a rotameter.


Dimensions

Dimensions

*Note: Details including specifications may change without notification.
